AIM 4420
Machining Centers
Technical Data
18 kW / 400V AC 3P+PE / 50/60 Hz.
Motor Power
3.000 RPM
Matkap Donus Hizi
20.000 RPM
Blade Speed
D: Ø180 mmd: Ø30-32 mm
Blade Diameter
250 L/min
Air Consumption
6-8 bar
Air Pressure
180x590x275
Dimensions
3.050 Kg / 2.850 Kg
Weight
STANDART AKSESUARLAR
- ✓ CAMPROX software program for CNC programming
- ✓ Keyboard & mouse set for programming
- ✓ Safety fence around the machine
- ✓ 4 x pneumatic profile clamps
- ✓ 2 x pneumatic rests
- ✓ Chip pan in the machine frame
OPSIYONEL AKSESUARLAR
- ✓ Cutter tools, tool holders and collets set
- ✓ CAD-EXTRACT software program for working on IGES files
- ✓ Automatic tool length measurement device
- ✓ Chip removal conveyor belt
- ✓ Special saw blade kit
- ✓ Hand-held controller
- ✓ 2 x additional clamps
- ✓ Barcode reader
GENEL OZELLIKLER
- ✓ It is designed to make operations on three surfaces of the profiles such as hole, slot, corner relieve, saw cutting, tapping, flow drilling etc.
- ✓ With its dual station operation feature, it can process two workpieces with one program without interruption. (AIM 7420 or AIM 7420T models)
- ✓ Automation system providing CNC motion at 4-axis
- ✓ 11 set magazine unit including cutter sets and saw blade with 180 mm diameter
- ✓ Flow drilling and rigid tapping feature from M4 to M10 with encoder spindle (AIM 4720T model)
- ✓ Automatic clamp recognition and positioning fature is available
- ✓ Special sound insulation cabinet around the machining unit
- ✓ PLC controlled 2-output tool cooling unit
- ✓ 4 pc of automatic clamps for AIM 4420 and 8 pc. for AIM 7420 are used to catch the workpieces. (the number of clamps can be increased optionally)
- ✓ 2 x pneumatic rests used for resetting the workpiece in X direction
- ✓ 21’’ colour touch screen
- ✓ Program import via USB flash memory stick
- ✓ Technical support via remote connection capability (via computer)
- ✓ Standard ISO ‘G’ code programming language
- ✓ Optimum operational safety guaranteed by 3-zone field scanner system
- ✓ Cartridge lubrication system for X, Y and Z axes
- ✓ Multi-language support
- ✓ LED lighting in the cabinet
